The Most Accurate Way

To Measure the Position of a tapped hole

Improve Efficiency
with Quick Repeatable Results

Tru-Pos Locators are Ideally Suited
for Locating the True Position of Threaded Holes

Easy to Use and Designed for Efficiency
Tru-Pos is the Market Leader
in True Position Locators

FAST, ACCURATE, CONSISTENT INSPECTION RESULTS.

Store

An essential component of any CMM package, TRU-POS LOCATORS are the only correct way to determine the true position of tapped holes.

ASME Y14.5 specifies that “any tolerance of orientation or position, and datum references, that are specified for a screw thread, apply to the axis of the thread derived from the pitch cylinder.”

Gage pins, screw heads or tap shanks are misused because they do not reference the pitch diameter. This can cause a misleading reading making an “in tolerance” hole seem “out of tolerance.”

Using TRU-POS, your inspection department can adhere to specifications with correct gaging methods and achieve faster throughput on the CMM.

This straight thread with a precision ground seating shoulder, designed for seating on a flat surface, is our most popular style of Tru-Pos Locator.
Finely ground threads are sized to .0001” (.0025mm) under a Class 2B go thread gage, with a -.0003” (-.0075mm tolerance).
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).
Certificate of Calibration is available to provide documentation of actual tolerance.
UNJ spec threads are fully compatible with these UN Tru-Pos Locators.

Shop Here
Use this Tapered thread style when you must not make contact with the face of your part due to surface irregularities, such as a cast or cylindrical surface.
The tapered thread incorporates the class 2 GO and NO GO pitch diameters, ensuring only contact with the pitch diameter.
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).
Certificate of Calibration is available to provide documentation of actual tolerance.
UNJ spec threads are fully compatible with these UN Tru-Pos Locators.
Shop Here
This straight thread with a precision ground seating shoulder is our most popular style of Tru-Pos Locator.
Finely ground threads are sized to .0001” (.0025mm) under a Class 6H go thread gage, with a -.0003” (-.0075mm tolerance).
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).
Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
Use this tapered thread style when you must not make contact with the face of your part due to surface irregularities, such as a cast or cylindrical surface.
The tapered thread incorporates the class 6H GO and NO GO pitch diameters, ensuring only contact with the pitch diameter.
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
Use to check thread position before the helical coil is inserted.
This straight thread with a precision ground seating shoulder, designed for seating on a flat surface, is our most popular style of Tru-Pos Locator.
Finely ground threads are sized to .0001” (.0025mm) under a go thread gage, with a -.0003” (-.0075mm tolerance).
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
Use to check thread position before the helical coil is inserted.
Use this tapered thread style when you must not make contact with the face of your part due to surface irregularities, such as a cast or cylindrical surface.
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
Use to check thread position before the helical coil is inserted.
This straight thread with a precision ground seating shoulder, designed for seating on a flat surface, is our most popular style of Tru-Pos Locator.
Finely ground threads are sized to .0001” (.0025mm) under a go thread gage, with a -.0003” (-.0075mm tolerance).
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).
NPT ring gage fits within one turn above or below the surface of TRU-POS locator.

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
This straight thread with a precision ground seating shoulder, designed for seating on a flat surface, is our most popular style of Tru-Pos Locator.
Finely ground threads are sized to .0001” (.0025mm) under a NPSF go thread gage, with a -.0003” (-.0075mm tolerance).
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
Thread major diameter truncated to fit the NPTF tolerance.
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
This straight thread with a precision ground seating shoulder, designed for seating on a flat surface, is our most popular style of Tru-Pos Locator.
Finely ground threads are sized to .0001” (.0025mm) under a BSPP go thread gage, with a -.0003” (-.0075mm tolerance).
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
Shop Here
The head diameter is concentric to the thread pitch diameter within .0002” TIR (.005mm).

Certificate of Calibration is available to provide documentation of actual tolerance.
